Configuring Terraform for Delinea Platform Integration

To integrate Terraform with Delinea Platform, you must copy and update required files from the Terraform provider GitHub repository:

• Terraform configuration files (.tf)

• Terraform variable files (.tfvars)

Step 1: Copy and Update the Terraform Configuration Files (.tf)

1. Go to the Delinea Terraform provider GitHub repository terraform-provider-tss/examples/secrets.

2. Copy the relevant example .tf file into your Terraform working directory. Rename them if needed (e.g., main.tf).

Use Case	Example File
Retrieve a single secret	examples/secrets/secret_get/main.tf
Retrieve multiple secrets	examples/secrets/secrets_get/main.tf
Create or update a secret	examples/secrets/secret_create/main.tf
Retrieve ephemeral secret	examples/secrets/ephemeral_secret_get/main.tf
Retrieve multiple ephemeral secrets	examples/secrets/ephemeral_secrets_get/main.tf
Delete Secret by id	examples/secrets/secret_delete/main.tf
Delete multiple secrets by their id	examples/secrets/secrets_delete/main.tf

3. Update each file with the required configuration definition.

• The required Terraform version

• The Delinea provider version (terraform-provider-tss)

• References to variables

• The type of secret-management operation to perform

4. Inside your copied .tf file, update the required provider block. This ensures Terraform uses the correct provider and version to communicate with Delinea Platform

Copy

terraform {
                required_version = "> 1.11.0"
                required_providers {
                tss = {
                source  = "DelineaXPM/tss"
                version = "4.0.0"
                }
                }
        }

Step 2: Copy and Update the Terraform Variable Files (.tfvars)

To ensure security when using Terraform with Delinea Platform, avoid storing user credentials in the .tfvars file or the .tfstate file in plain text. Use one of the supported secure methods below to protect sensitive information during infrastructure provisioning. Ephemeral resources are temporary and short-lived. They are not persisted in the Terraform state file, making them ideal for managing sensitive secrets such as usernames, passwords, or tokens.

The variable files define the values required by your configuration file.

Navigate to terraform-provider-tss/vars/secrets and choose .tfvars file that fits your use case:

Static Credential Variables

The following variables must be updated in the files (secret_get.tfvars and secrets_get.tfvars):

Example: secret_get.tfvars

Use only tss_username and tss_password or tss_token in secret_get.tfvars depending on whether you use credentials or token-based authentication.

Credentials authentication

                tss_username   = "username"
                tss_password   = "password"
                tss_server_url = "https://yourtenantname.delinea.app"
                tss_secret_id  = 1

Token authentication

                tss_token      = "token"
                tss_server_url = "https://yourtenantname.delinea.app"
                tss_secret_id  = 1

Example: secrets_get.tfvars

Use only tss_username and tss_password or tss_token in secrets_get.tfvars depending on whether you use credentials or token-based authentication.

Credentials authentication

                tss_username   = "username"
                tss_password   = "password"
                tss_server_url = "https://yourtenantname.delinea.app"
                tss_secret_id  = ["1", "2", "3"]

Token authentication

                tss_token      = "token"
                tss_server_url = "https://yourtenantname.delinea.app"
                tss_secret_id  = ["1", "2", "3"]

Using Environment Credential Variables

Direct Provider Environment Variables

The provider reads these variables directly. No TF_VAR_ prefix is required, and the provider block can be empty:

Configure either TSS_USERNAME plus TSS_PASSWORD, or TSS_TOKEN; do not configure both authentication methods. TSS_SERVER_URL is required.

Terraform input variables with the TF_VAR_ prefix remain a separate supported mechanism. Use TF_VAR_tss_username, for example, only when the Terraform configuration declares and references a variable named tss_username.

Starting with provider v5.0.0, a provider attribute whose value is unknown during configuration produces an error instead of falling back to a TSS_* environment variable. Either set the provider attribute statically or leave it unset and use the environment variable exclusively.

Server URL Requirements and Backend Probe (v5.0.0)

• tss_server_url must use https:// for any remote host. Provider v5.0.0 rejects a plaintext http:// URL to a non-loopback host at configure time; terraform plan and terraform apply fail with an error naming the allow_insecure_http opt-in. Set allow_insecure_http = true on the provider block, or export TSS_ALLOW_INSECURE_HTTP=true, only when you deliberately accept plaintext HTTP.

• With username/password authentication, the provider sends an unauthenticated GET to <tss_server_url>/api/v1/healthcheck and then <tss_server_url>/health before sending credentials, so it can distinguish Secret Server from Delinea Platform. The endpoint must answer with a direct 2xx response; redirects are not followed. Allow the health path through any proxy in front of the tenant before upgrading. Token authentication skips the probe.

Ephemeral Resource Support (Preferred Method)

The Terraform provider now supports ephemeral resources using the latest Terraform Plugin Framework. Ephemeral resources are temporary, short-lived entities created during the execution of the terraform application operation. They are not persisted in the Terraform state file or any other Terraform-managed storage, offering enhanced security for managing sensitive data such as username, passwords, and API tokens.

Usage Example

In your .tf file, use the ephemeral block:

ephemeral "tss_secret" "my_username" {
                    id    = var.tss_secret_id
                    field = "username"
                    }
                    ephemeral "tss_secret" "my_password" {
                    id    = var.tss_secret_id
                    field = "password"
                }

These values can be dynamically injected into other Terraform resources:

resource "print_resource" "print_username" {
                    secret = ephemeral.tss_secret.my_username.secret_value
                    }
                    resource "print_resource" "print_usernames" {
                    secret = ephemeral.tss_secrets.my_usernames.secrets
                }

Sample Terraform files demonstrating the use of ephemeral resources are available in the terraform-provider-tss/examples/secrets directory for reference. For more details and examples on using ephemeral resources, see Ephemeral Resource Support for Improved Security.

SSH Keys and Passphrase Generation in Terraform Provider for TSS

To generate SSH keys and a passphrase when creating a secret using templates that include SSH key and passphrase fields, you need to set the generate_passphrase and generate_ssh_keys flags to true. By default, these flags are set to false.

To Pass SSH Key and Passphrase Generation Arguments from Terraform Variable File:

fields = [
                    {
                    fieldname = "Public Key"
                    itemvalue = null
                    },
                    {
                    fieldname = "Private Key"
                    itemvalue = null
                    },
                    {
                    fieldname = "Private Key Passphrase"
                    itemvalue = null
                    }
                    ]

                    # SSH Key Generation Settings
                    generate_passphrase = true
                generate_ssh_keys   = true

Important Notes

1. Set itemvalue to null for SSH key fields.

2. Set the appropriate boolean values for generate_passphrase and generate_ssh_keys.

Limitations and Considerations

• Creation only: SSH key generation is only supported during secret creation, not during updates.

• Field values: When updating a secret with previously generated SSH keys, the provider automatically preserves the generated values.

• Changing sshkeyargs replaces the secret (v5.0.0): the block is replacement-only, so editing generatepassphrase or generatesshkeys produces a destroy-and-create plan instead of an in-place no-op.

Delete Secret

This functionality deactivates the secret in Delinea Secret Server. It does not permanently delete the secret, but renders it inaccessible.

Delete Secret by ID

The tss_secret_deletion resource allows you to delete a secret by its ID, even if it is not managed by Terraform state. Use the following block in your .tf file:

resource "tss_secret_deletion" "delete_secret" {
                    secret_id = var.tss_secret_id
                }

Apply this configuration to delete the secret with the ID provided in your Terraform variable file. After deletion, run terraform destroy to remove the resource from state before deleting another secret.

Delete Multiple Secrets

The tss_secret_deletion resource also supports deleting multiple secrets by their IDs, even if they are not managed by Terraform state. Use the following block in your .tf file:

resource "tss_secret_deletion" "delete_secrets" {
                    for_each  = toset(var.tss_secret_ids)
                    secret_id = tonumber(each.key)
                }

This configuration deletes all secrets listed in the set provided from the Terraform variable file. Each deletion is tracked separately in state.

Important Notes

• After deleting, run terraform destroy to clean up the state before deleting new secrets.

• Deletion is performed during the terraform apply phase.

• The resource is tracked in state to prevent repeated deletion attempts.

• Creating... in logs indicates the deletion is being performed.

• v5.0.0: tss_secret_deletion is a one-shot operation. If the deleted secret is later restored, refresh reports a warning and keeps the completed operation in state; Terraform does not delete the restored secret again. Remove the resource from state and apply again only when another deletion is intended.

• v5.0.0: changing secret_id on an existing tss_secret_deletion resource now replaces the resource, so the newly selected secret is actually deleted. Earlier versions rewrote the state record without deleting the new target.

Step 3: Complete Configuration

After completing the configuration, your Terraform executable directory should include:

• The .tf configuration file

• The .tfvars variable file

• Terraform executable (terraform)

Upgrading to Provider v5.0.0

Terraform state from provider v4.0.x is compatible with v5.0.0, but configurations must be reviewed before upgrading. Use Terraform 1.11 or later, allow the Delinea Platform /health endpoint to return a direct 2xx response when username/password authentication is used, migrate password fields from itemvalue to password_value plus password_wo_version, remove configured computed field metadata, and add an unambiguous fieldname to every fields block. Changing sshkeyargs now replaces the secret. Managed-secret and multi-secret reads now fail closed instead of silently replacing or shortening results. Pin version = "~> 4.0" until these changes are complete.
